INFRARED MODULES AND SYSTEMS
For more than 70 years Helios Quartz has made IR quartz emitters in short, medium and fast medium wavelengths, and the infrared modules and systems that hold them for industrial heating processes. A module turns individual emitters into a ready-to-fit heating unit.
What a Helios IR module includes
Each module is supplied fully cabled and fitted with a thermal sensor for high temperature. It is prepared to hold Helios infrared quartz emitters and Helios quartz protection plates, so the heating elements and their shielding drop straight in.
Built around your line
Working with the customer, Helios customizes the module design to the application and supplies heating modules and control systems that fit both new and existing lines. Complete systems are built up to 6.5 metres in length and can be equipped with the options below.
|
Option |
Purpose |
|---|---|
| High-temperature thermal switch | Temperature control and protection |
| Air or water cooling system | Manage heat in and around the module |
| Air knife / exhaust design | Airflow and extraction for the process |
| System length | Up to 6.5 metres |
Applications
IR modules and systems serve continuous industrial heating, drying and curing lines where individual emitters need to be cabled, controlled and cooled as one unit. The emitter wavelength is chosen to match the material, then built into the module.
FAQ
How long can a system be?
Helios builds infrared modules and systems up to 6.5 metres in length.
Which emitters do the modules use?
They are prepared for Helios IR quartz emitters in short, medium and fast medium wavelengths, plus Helios quartz protection plates.
Can a module be fitted to an existing line?
Yes. Modules and control systems are designed to fit both new and existing lines.
Share your line layout and process target to scope a module or full system.
